Kit Building with 4m Canopy - 290m²

Request a free quote

Building details

Shape and sizes

Building area : 216.00m2
Type of slope : Single sloped (16%)
Width : 12m
Length : 18m
Height: 5m
Rafter section : Ⅰ 200mm
Post section : Ⅰ 200mm
Purlins : C180mm galvanized

Covering

Type of roofing : 0.63mm lacquered sheet metal
Ridge : Flat & Extra large
Side Bracing : Included
Bolts and fasteners : Included

Specificities

Specificity 1 : 4m canopy offering you an additional 72m² of covered area

Description

Take advantage of our kit building with a total width of 12m (8m + 4m canopy) offering you a total surface of 290m² with a hot-dip galvanized structure and a 1st choice 5-wave sheet metal cover. The 4m wide canopy makes it a versatile building that can be used both as an industrial warehouse and suitable agricultural storage shed. Robust, durable; and economical, this kit building is available in stock at the best value for money on the market.



Robustness and resistance



Savings and sustainability thanks to the rust protection effect of hot-dip galvanization

  • Steel frame and elements are protected from rust for many years
  • No maintenance costs over the very long term, unlike a painted structure that requires regular touch-ups



Easy delivery and assembly

  • Kit building delivered with its assembly plans to the address of your choice or the nearest port
  • Easy assembly using a lifting device and a few tools, even without technical knowledge thanks to the pre-drilled structure


Manufacturer's insurance and tax-free billing



The best value market price

  • The budget focused on your primary need: you only spend on the essentials and not the accessory.
  • 20 years of expertise and hundreds of customers testify that our prices are the most competitive on the market



The prices are exclusive of taxes and transport costs. These costs will be communicated to you at the time of your quote.
Building eligible for installation up to a maximum altitude of 260m only.
Illustration photo not contractual.




Available options

Translucent sheets, smoke vents, zenithal vault: let in natural light to save energy
Reinforcement of roof's static load in order to receive photovoltaic panels
Condensation controller
Galvanized interlocking gutters with high evacuation rate
Cladding: Enclose your metal building
Insulation with our sandwich panels: eliminate temperature differences to benefit from a comfortable work space
Openings: adapt the space to your business: sliding door, sectional door, metal curtain, windows
Additional 5 and 6m spans: increase the surface area and length of the building
Canopies: add a second canopy to increase the covered area
Mezzanine: increase the usable area of your building and create independent spaces
Overhead crane or a feed claw: we adapt the resistance of the building and provide you with a runway
Hinged mounting on base plate, mounting at level 0 instead of flush mounting
